325 Mesh Energy Saving Consumption Reduction 85-730t Raw Mill Vertical Mill
Description:
Vertical mill has advantages in cement raw meal grinding.
The grinding method of the vertical mill is to roll the material layer. In addition to its own powder selection device, the discharge of raw materials can avoid over crushing on the basis of meeting the fineness. Because the raw cement materials have strict requirements on the fineness of raw materials, this is the basis for the vertical mill to apply to the grinding of raw cement materials. In addition, the feed size of vertical mill is relatively large. Compared with ball mill, the secondary crushing device can be omitted, and the land occupation and power consumption are smaller and lower than those of backward ball mill. For example, the power consumption is 40% or more less than that of ball mill.
In the vertical mill cement raw meal grinding, 20 years of mill manufacturing experience, especially the large number of customers accumulated by the vertical mill, let us make continuous progress in user feedback and self-improvement. I believe Hefei Hengcheng is worthy of your trust. If you want to know about the equipment or our company, please contact us, and we will return your trust with a dedicated attitude.
Specifications and Technical Parameters of HVM Raw Vertical Mill
| Model Specifications | HVM2500 | HVM2800 | HVM3400 | HVM3700 | HVM4200 | HVM4500 | HVM4800 | HVM5100 | HVM5600 |
| Grinding Table Median Diameter(mm) | 2500 | 2800 | 3400 | 3700 | 4200 | 4500 | 4800 | 5100 | 5600 |
| Capacity(t/h) | 85-100 | 130-160 | 190-240 | 240-300 | 320-400 | 400-500 | 440-550 | 550-670 | 600-730 |
| Raw Material Moisture | ＜10% |
| Raw Meal Fineness | R0.08＜12% | R0.08＜14% |
| Raw Meal Moistrue | ≤1% |
| Main Motor Power(kW) | 800/900 | 1120/1250 | 1800/2000 | 2500/2800 | 3150/3350 | 3800/4200 | 4200/4500 | 5000/5400 | 5600/6000 |
| Illustrate | Re:Raw materials bond index≤13kWh/t | |
Advantages
Vertical mill is an ideal large-scale grinding equipment, which is widely used in cement, electric power, metallurgy, chemical industry, non-metallic mine and other industries. It integrates crushing, drying, grinding and grading transportation, and has high production efficiency. It can grind block, granular and powdery raw materials into required powdery materials.
1. High grinding efficiency and low power consumption;
2. Less metal consumption per unit product;
3. The process flow is simple, and the functions of material grinding, drying and powder selection are completed at the same time;
4. Small floor area, compact layout, light weight of system equipment, low investment in civil construction.
After-sale Service
We have a long-term service in the production line, good technology, responsible after-sales service team. All members have more than 5 years of experience and can provide customers with timely, efficient, comprehensive and scientific after-sales service. It can provide customers with the whole process of after-sales service from engineering construction, production line equipment installation, production line commissioning to production line reaching the standard, solve various difficulties and miscellaneous problems encountered by customers, and provide thoughtful, meticulous and perfect after-sales service.
